HALFSHAFT Bearing: Removal

    WARNING: Do not work on or under a vehicle supported only by a jack. Always support the vehicle on safety stands.
  1. Raise and support the vehicle.
  2. Remove the wheel and tire.
  3. Remove and discard the halfshaft oil seal. See HALFSHAFT .
  4. Using the special tool, remove and discard the halfshaft bearing.
    GJ0014661
